Aquascape PL and PN Solids-Handling Pond Pumps
World-renowned for their quality, dependability, and performance, Aquascape PL and PN series pumps are ideal for use in skimmer filters and Pondless Waterfall applications.
Constructed of stainless steel and composite resin for strength and corrosion resistance; with a semi-vortex impeller design enabling the pump to handle solids effectively. Resulting in less maintenance and trouble-free performance.
Engineered for Years of Use
Engineers have designed the Aquascape PL series pump to be hydraulically ‘dialed’ into the lower total dynamic head ranges typically found on water feature applications, helping increase the lifespan of the pump by reducing vibration and premature component wear.
The energy-efficient, continuous-duty, direct-drive motor operates at lower temperatures, extending the life of the pump significantly. Each PL and PN Solids-Handling Pond Pump also contains a built-in thermal overload, protecting it from damage if ever run in low-water conditions.
Compare Aquascape PL and PN Solids-Handling Pond Pumps
 |
 |
 |
 |
 |
|
|---|---|---|---|---|---|
| 3PL | 5PL | 9PL | 8PN | 12PN | |
| View Product | View Product | View Product | View Product | View Product | |
| Model Number | 29975 | 29976 | 29977 | 29495 | 30391 |
| Maximum Flow Rate (GPH) |
3,300 | 5,300 | 7,300 | 5,548 | 10,000 |
| Maximum Head Height |
14 feet | 23 feet | 35 feet | 56 feet | 23 feet |
| Motor Type | Direct Drive | Direct Drive | Direct Drive | Direct Drive | Direct Drive |
| Wattage | 320 | 620 | 1000 | 1000 | 900 |
| Amperage | 3.1 | 5.6 | 8.6 | 9.1 | 9.1 |
| Power Cord Length |
20 feet | 20 feet | 20 feet | 20 feet | 20 feet |
| Pump Discharge Diameter |
2 inch | 2 inch | 2 inch | 2 inch | 3 inch |
| Optimum Pipe Diameter |
1.5 - 2 inch | 1.5 - 2 inch | 2 or 3 inch | 2 or 3 inch | 3 inch |
| Pump Dimensions |
12.2 x 5.6 x 7.1 inches (LxWxH) |
13.2 x 5.9 x 7.3 inches (LxWxH) |
14 x 5.9 x 7.3 inches (LxWxH) |
9.3 x 6.4 x 15 inches (LxWxH) |
11.7 x 7.7 x 15.1 inches (LxWxH) |
| Warranty (Limited) | 2 years | 2 years | 2 years | 2 years | 2 years |
